Flanged cup Bearing

Page 1



A-A

A-B

A-C

ITEM NO.

DIMENSION(mm)

BALL

D

d

A

H

h

B

DIA.

NO.

A-A01

23

11.2

26

9.4

62

2

5/32'

12

A-A02

28.6

12.7

32

11.5

81

2

5/32'

16

A-A03

35

16

38

12

98

1

1/4'

10

A-A04

50.8

25.6

54

17

11.4

3.5

1/4'

19



















A-B01

23

11.2

26

9.4

6.2

2

1/8'

16

A-B02

28.6

12.7

32

11.5

81

2

3/16'

13

A-B03

35

16

38

12

98

1

5/32'

20

A-B04

50.8

25.6

54

17

11.4

3.5

1/4'

19

A-B05

50.8

25.7

54

16.2

11.4

2.8

1/4'

19

A-B06

50.8

25.5

54

16.2

11.4

2.8

1/4'

19

A-B07

50.8

25.7

54

19.4

11.4

6

1/4'

19



















A-C01

23

8

25.2

11

7.8

1.6

1/8'

17

A-C02

27

9.5

30

11.2

8

1.6

5/32'

15

A-C03

27

8

30

11.2

8

1.6

5/32'

15

A-C04

28.6

12.8

31.6

12.8

8

3.2

5/32'

16

A-C05

50.8

25.6

54

17

11.4

3.5

1/4'

19









Flanged cup bearing

Page  2

JHG-A

JHG-B

ITEM NO.

DIMENSION(mm)

BALL

A

d

D

H

h

DIA.

NO.

JHY-A01

43.6

12

40

16.7

11

1/16'

15

JHY-A02

50

15

47.7

20

16

1/16'

15

















JHY-B01

50.7

12

47.8

16.6

14.1

1/16'

13

















JHY-C01

50.8

8.2

79.6

13.3

11.2

1/16'

12







Flanged cup bearing

Page  3

I-A

I-B

ITEM NO.

DIMENSION(mm)

BALL

A

d

D

H

h

DIA.

NO.

I-A01

25

8

23.6

14.5

9.5

1/8'

15

I-A02

38

12

35.3

15.5

11.5

5/32'

18

I-A03

50

12

47.6

18

13

3/16'

19

I-A04

60

12

56

20.2

15.6

1/4'

17

I-B01

25

8

23.6

14.5

9.5

1/8'

15

I-B02

38

12

35.6

15.5

11.5

5/32'

18

I-B03

50

12

47.6

18

13

3/16'

19

I-B04

60

12

23.3

20.2

15.6

1/4'

17







Flange bearing

Page  4

J



J-B

ITEM NO.

DIMENSION(mm)

BALL

D

d

H

h

NO.

DIA.

J-01

23

11.2

15

8

9

1/8'

J-02

28

13.1

15

8

9

1/8'

J-03

35

16.8

28

8.5

9

5/32'

J-04

50

25.6

23

10

9

1/4'









Special ball bearing

Page 5

E-A



E-B

ITEM NO.

DIMENSION(mm)

BALL

D

d

H

h

NO.

DIA.

E-A01

28

10.1

8

7.6

13

5/32'

E-A02

28

12.1

8

7.6

13

5/32'

E-A03

28

10.1

10.1

7.6

13

5/32'

E-A04

28

12.1

10.1

7.6

13

5/32'

E-A05

28

12.3

11.8

7

13

5/32'
